Product Overview
Precast Latitude™ Midigels TBE are made for accurate DNA fragment separation for most any gel electrophoresis application. They are manufactured from high quality, Lonza molecular biology grade SeaKem® LE Plus Agarose. These ready-to-run gels are available in two different well formats and agarose concentrations in TBE buffer to fit most DNA electrophoresis needs. Our Latitude™ Precast Agarose Gels are precision cast for accurate, reproducible resolution of DNA fragments for 100 bp to 8 kb and prestained with 0.5 µg/ml Ethidium Bromide. Latitude™ Midigels TBE fit most standard electrophoresis chambers and are stable for 6 to 12 months, depending on their concentration. All Latitude™ Midigels TBE have a well volume of 10 µL to 12 µL. They are are packaged 8 gels/box.
Specifications
Separation range 300 bp to 8 kb
Gel per box 8
Gel dimensions 10 cm × 15 cm
Gel thickness 6.0 mm
Ethidium bromide 0.5 μg/mL
Tray dimensions 10.4 cm × 15.6 cm
Well volume 10 μL–12 μL
Available formats of Latitude™ Midigel Gels TBE
Catalog # |
Gel concentration |
Number of wells |
Separation range |
57220 |
1 % |
20 wells |
300 bp to 8 kb |
57230 |
1 % |
2 x 20 wells |
300 bp to 8 kb |
57239 |
2 % |
15 wells |
100 bp to 2 kb |
57231 |
2 % |
2 x 20 wells |
100 bp to 2 kb |
Benefits
Fast - No more pouring or cooling times
Easy - simply unwrap and use
Traceable - trackable lots
Applications
DNA Electrophoresis
Catalog #: 57220 -- 20-well
Catalog #: 57230 -- 2x20-well
Please email us at cs@medikonia.com for any enquiry. To place an order, please include the catalog number(s) of the product(s) in the email.
